Low price, high standard of service is the quick way to describe the Type 891. The electromechanical time counter has a 7-digit display and convenient screw terminals. Standard DIN dimensions of 48 x 24 mm and no less than six different fitting frames simplify installation. This counter does not have a reset function.
Unit of Measure

Technical Specs

Brands

 N/A
Hengstler

Model

 N/A 891

Type

 N/A Time Counter

Display

 N/A 7-digit, 0 to 99999.99 h

Digit Height

 N/A 5 mmVisual

Operating Temperature

 N/A -10 to 50 ºC

Storage Temperature

 N/A -20 to 70 ºC

Supply Voltage Vop

 N/A According to order information + 10 % (230 VAC + 15 %)

Power Consumption

 N/A 0.7 VA or max 750 mW on Direct Current (DC)

Electrical Connection

 N/A Screw terminals for cables of max. 2.5 mm² and AMP connector 6.3 x 0.8 mm

Mounting

 N/A With clamping frame (Ordering code 2 891 016)

Mounting Position

 N/A Roller Axis Horizontal

Protection Class (IEC 144)

 N/A Front Ingress Protection (IP66); screw terminals Ingress Protection (IP20), AMP connectors Ingress Protection (IP00)

Vibrostability

 N/A 30 m/s² (10 ... 500 Hz) According to IEC 068-2-6

Features

N/A

  • Low-cost
  • DIN dimensions 24 x 48 mm, 48 x 48 mm or 72 x 72 mm
  • Highly legible display
  • Simple installation
  • No reset
