Type 886-887 has impressively compact dimensions. The front panel is available in different sizes and is variable. This electromechanical adding preset counter can be supplied with an electric or manual reset function. The display is available as a 3 or 5-digit version with permanently visible presets.
Unit of Measure

Technical Specs

Brands

 N/A
Hengstler

Model

 N/A 886/887

Type

 N/A Preset Counter

Display

 N/A 3 or 5-digit indication of count and preset value, depending on version

Digit Height

 N/A 4 mm

Residual Ripple

 N/A 48 %

Operating Temperature

 N/A -10 to 50 ºC

Storage Temperature

 N/A -40 to 85 ºC

Supply Voltage Vop

 N/A See ordering code table, tolerance ± 10 %
230 VAC + 6–10 %

Power Consumption

 N/A Counter: Direct Current (DC) Version 2.5 W, Alternating Current (AC) Version 2.75 VA
Reset Solenoid: Direct Current (DC) Version 12 W, Alternating Current (AC) Version 16 VA

Electrical Connection

 N/A AMP connector, 0.8 x 2.8 mm

Mounting

 N/A Screw or clamping spring attachment, see "Order information"

Mounting Position

 N/A Roller Axis Horizontal

Features

N/A

  • Preset value continuously visible
  • Manual or electric reset
  • 3 or 5-digit indication
  • Various front panel sizes available
