Type 864-868 is a compact individual unit available with 4, 6, or 8-digit display. The device is available without a reset, or with a manual or electric reset option. The electro-mechanical totalizing counter stands out because of its user-friendly design.
Unit of Measure

Technical Specs

Brands

 N/A
Hengstler

Model

 N/A 864-868

Type

 N/A Totalizing Counter

Display

 N/A 6 or 8-digit, depending on version

Digit Height

 N/A 4 mm

Operating Temperature

 N/A -10 to 50 ºC

Storage Temperature

 N/A -20 to 70 ºC

Supply Voltage Vop

 N/A According to order information, tolerance ± 10 %
230 VAC + 6–10 %

Power Consumption

 N/A Direct Current (DC) Counter: 2.5 W/VA, Reset Magnet 12 W/VA
Alternating Current (AC) Counter: 2.75 W/VA, Reset Magnet 16 W/VA

Protection Class (EN 60529)

 N/A Front Ingress Protection (IP40); Connections Ingress Protection (IP00)

Vibrostability

 N/A 50 m/s² According to IEC 068-2-6

Shock Stability

 N/A 600 m/s² (6 ms) According to IEC 068-2-27

General Design

 N/A EN 61010-1, EN 50178; contamination level 2 VDE 0110

Approximate Weight

 N/A 90 g

Features

N/A

  • 6 or 8-digit display
  • with manual/electrical reset or without reset
  • Simple installation
  • Various front panel sizes
