The Model 58TP programmable 58 mm Accu-CoderPro® thru-bore encoder is specifically designed for the challenges of an industrial environment. Its advanced set of electronics allow the encoder to be programmed to meet your exact application needs. Using EPC's optional programming module, users may select the output type, 32 different waveforms, and any resolution from 1 to 65,536 CPR - 262,144 counts using 4x quadrature counting. These programming features allow a single encoder to be configured for multiple applications, enabling one encoder to replace many different part numbers, providing cost savings on inventory and down-time replacement. The Model 58TP can also be configured and shipped with specs pre-programmed, with no on-site programming needed.
Unit of Measure

Technical Specs

Brands

 N/A
Encoder Products Company

Model

 N/A 58TP

Type

 N/A Encoder

Maximum Shaft Speed

 N/A 6000 rpm. Higher shaft speeds may be achievable, contact Customer Service.

Shaft Material

 N/A 303 Stainless Steel

Shaft Rotation

 N/A Bi-Directional

Moment of Inertia

 N/A 5.5 x 10-4 oz-in-sec2

Housing

 N/A Black Non-Corrosive Finish

Non-Condensing Relative Humidity

 N/A 98 %

Common Applications

N/A Motor Control, Conveyors, Elevator Controls, Machine Control, Food Processing, Process Control, Robotics, Material Handling, Textile Machines, and all types of motion feedback.

Features

N/A

  • Programmable resolution from 1 to 65,536 CPR
  • Programmable output type and waveform
  • Programmable with USB module or factory configured when ordered
  • 58 mm thru-bore or blind hollow bore
  • Standard and metric bore sizes up to 5/8" and 15 mm
  • Flexible mounting options
  • Sealing to IP67
