The Model 716 Accu-Coder® is ideally suited for applications requiring a quadrature output. Designed for compatibility with most programmable controllers, electronic counters, motion controllers, and motor drives, it is ideally suited for industrial applications where it is important that the direction of rotation be known. Critical performance specifications for the most popular resolutions and advanced Opto-ASIC circuitry - a single chip design that eliminates many board level components - increase the reliability of an already dependable and durable encoder. With new options continually being added, the Model 716 excels in a wide variety of industrial applications.
Unit of Measure

Technical Specs

Brands

 N/A
Encoder Products Company

Model

 N/A 716

Type

 N/A Shaft Encoder

Maximum Shaft Speed

 N/A 6000 rpm. Higher shaft speeds achievable, contact Customer Service.

Shaft Material

 N/A 303 Stainless Steel

Housing

 N/A Black non-corrosive finished 6063-T6 aluminum

Bearings

 N/A Precision ABEC Ball Bearings

Moment of Inertia

 N/A 6.5 x 10-6 oz-in-sec2

Storage Temperature

 N/A -25 to 85 ºC

Non-Condensing Relative Humidity

 N/A 98 %

Vibration

 N/A 10 g @ 58 to 500 Hz

Shock

 N/A 50 g @ 11 ms duration

Common Applications

N/A Feedback for counters, PLCs & motors, cut-to-length, labeling, measuring for packaging, filling & material handling machines, wire winding, film extrusion

Features

N/A

  • The original industry-standard Cube
  • Versatile housing styles
  • Quadrature output
  • New resolutions to 10,000 CPR
