The compact, industry standard 2-inch diameter Model 702 Motor Mount Accu-Coder® is designed to withstand harsh factory and plant floor environments. The mounting flange, with integral shaft and coupling, allows for easy installation on a motor or shaft assembly, without the need for additional brackets or couplings. With the ability to handle shaft speeds of up to 8000 RPM and withstand the shock and vibration of high speed servo motors, the Model 702 Motor Mount Accu-Coder® is heavy-duty, ultra-rugged, and reliable.
Unit of Measure

Technical Specs

Brands

 N/A
Encoder Products Company

Model

 N/A 702 Motor Mount

Type

 N/A Encoder

Maximum Shaft Speed

 N/A 8000 rpm. Higher speeds may be achievable, contact Customer Service.

Housing

 N/A Black Non-Corrosive Finish

Bearings

 N/A Precision ABEC Ball Bearings

Moment of Inertia

 N/A 5.2 x 10-4 oz-in-sec2

Storage Temperature

 N/A -25 to 85 ºC

Non-Condensing Relative Humidity

 N/A 98 %

Vibration

 N/A 20 g @ 58 to 500 Hz

Shock

 N/A 75 g @ 11 ms duration

Common Applications

N/A Servo and Stepper Motor Control, Robotics, X-Y Positioning Tables, Machine Tools

Features

N/A

  • Up to 30,000 CPR
  • IP66 sealing available
  • Mounting flange available with boss
