The Model 58TF 58 mm Accu-Coder® thru-bore encoder offers the high performance and advantages of the programmable Model 58TP, but in a fixed resolution version. The versatile Model 58TF offers 6 output types, 32 different waveforms, and any resolution from 1 to 65,536 CPR (262,144 counts using 4x quadrature counting). This encoder is also highly mechanically configurable. Specifically designed for the challenges of industrial environments, the Model 58TF can take on your demanding applications.
Unit of Measure

Technical Specs

Brands

 N/A
Encoder Products Company

Model

 N/A 58TF

Type

 N/A Encoder

Maximum Shaft Speed

 N/A 6000 rpm. Higher speeds may be achievable, contact Customer Service.

Shaft Material

 N/A 303 Stainless Steel

Shaft Rotation

 N/A Bi-Directional

Housing

 N/A Black Non-Corrosive Finish

Moment of Inertia

 N/A 5.5 x 10-4 oz-in-sec2

Non-Condensing Relative Humidity

 N/A 95 %

Vibration

 N/A 10 to 2000 Hz A 20 g (International Standard IEC 60068-2-6)

Shock

 N/A 80 g @ 6 ms Duration (International Standard IEC 60068-2-27)

Common Applications

N/A Motor Control, Conveyors, Elevator Controls, Machine Control, Food Processing, Process Control, Robotics, Material Handling, Textile Machines, and all types of motion feedback.

Features

N/A

  • 58 mm thru-bore or blind hollow bore encoder
  • Standard and metric thru-bore sizes up to 5/8" and 15 mm
  • Resolutions from 1 to 65,536 CPR
  • Flexible mounting options
  • Multiple connector options
  • Sealing to IP67
