The Model 15S Accu-Coder™ offers a high performance feedback solution in a low profile package, making the Model 15S ideal for commercial and light-duty industrial applications. This industry standard Size 15 (1.5" diameter) encoder features a precision bearing set, sealing available to IP64, a durable stainless steel shaft, and a selection of servo, flange, and face mount options. The Model 15S may also be specified with features such as extended operating temperatures from -40º C to 120º C, and up to 12 pole commutation for brushless motor control. The Model 15S features EPC's Opto-ASIC circuitry for a clean, reliable signal. Its durable yet economical design makes it an ideal encoder for high precision OEM applications.
Unit of Measure

Technical Specs

Brands

 N/A
Encoder Products Company

Model

 N/A 15S

Type

 N/A Shaft Encoder

Maximum Shaft Speed

 N/A 8000 rpm. Higher speeds may be achievable, contact Customer Service.

Shaft Material

 N/A Stainless Steel

Radial Shaft Load

 N/A 5 lb max. Rated load of 2 to 3 lb for bearing life of 1.2 x 1010 revolutions

Axial Shaft Load

 N/A 5 lb max. Rated load of 2 to 3 lb for bearing life of 1.2 x 1010 revolutions

Moment of Inertia

 N/A 6.7 x 10-5 oz-in-sec2 (4.8 gm-cm2)

Storage Temperature

 N/A -25 to 85 ºC

Non-Condensing Relative Humidity

 N/A 98 %

Vibration

 N/A 10 g @ 58 to 500 Hz

Shock

 N/A 80 g @ 11 ms duration

Common Applications

N/A Servo Motor Control, Robotics, Medical Diagnostic Equipment, Specialty Assembly Machines, Digital Plotters, Printers, Typesetting Equipment

Features

N/A

  • High performance economical encoder
  • Low profile - less than 1.0" (25.4 mm) height and 1.5" (38 mm) diameter
  • Extended temperature operating ranges available
  • Up to 12 pole commutation optional (for brushless motor control)
