The Model A58SE is an EtherCAT®, EtherNet/IP™, or PROFINET® protocol, multi-turn absolute encoder designed for heavy-duty industrial applications. It is particularly suited to applications where Ethernet-based connectivity is required, and the encoder must retain position information after power-off events. Easily designed into a wide variety of system applications, the A58SE plugs directly into your network with minimal provisioning for rapid deployment, facilitating data exchange among myriad networked devices. The Model A58SE retains absolute position information even after a power loss, facilitating speedy system recovery at start-up without the need for system re-homing.
Unit of Measure

Technical Specs

Brands

 N/A
Encoder Products Company

Model

 N/A A58SE

Type

 N/A Encoder

Shaft Material

 N/A Stainless Steel

Power Supply

 N/A 10 VDC up to 32 VDC

Typical Current Consumption

 N/A 125 mA

Typical Power Consumption

 N/A 3 W

Internal Cycle Time

 N/A 50 µs

Flange

 N/A Clamping Clamping Compact Clamping Heavy-Duty Synchro

Flange Material

 N/A Aluminum

Common Applications

N/A Robotics, Telescopes, Antennas, Medical Scanners, Wind Turbines, Elevators, Lifts, Motors, Automatic Guided Vehicles, Rotary and X/Y Positioning Tables

Features

N/A

  • Single turn/multi-turn absolute encoder (16 Bit ST / 43 Bit MT)
  • Available in three industrial ethernet protocols:
    • EtherCAT® with CoE, FoE, EoE - device profile: CiA DS-406 V4.0.2, Class 3
    • EtherNet/IP™ position sensor, DLR
    • PROFINET® I-O (CC-C) - device profile: switchable V4.1, Class 3, 4
  • Maintenance-free and environmentally friendly magnetic design
  • Energy harvesting magnetic multi-turn technology
  • No gears or batteries
  • Low TCO and easy provisioning with internal web server
  • Shaft loads up to 400 N
  • Color LEDs for operating condition, bus status, link activity
  • Compact design with bus cover
  • MP housing option is the most compact ethernet model available
  • 58 mm (2.28") diameter package

Additional Information

N/A Ready for Industry 4.0 and for the Industrial Internet of Things (IIoT), data exchange between the Model A58SE and other applications has no influence on the control loop. The Model A58SE is non-reactive and can work independently from the PLC or master, transferring data through network gateways to other automation networks and sites, and up to the cloud for analysis.
