Adjustable timing as a percentage of overall cycle... ideal for heat control, machine lubrication, etc.

The HQ9 offers accurate, efficient control for many industrial applications. These include motion control, electric heaters, ovens, program temperature controls, chemical feeding, and lubrication systems.
Unit of Measure

Technical Specs

Brands

 N/A
Eagle Signal

Model

 N/A HQ9

Type

 N/A Percentage Timer

Voltage/Frequency

 N/A 120 V (+10, -15%), 50/60 Hz
240V (+10, -15%), 50/60 Hz

Temperature Range

 N/A -10 to 140 ºF-23 to 60 ºC

Contact Rating

 N/A 1/2 Amp at 125 VDC 1/3 HP at 125/250 VAC 1/4 Amp at 250 VDC 10 Amps at 120/240 VAC

Setability

 N/A ± 1%

Maximum Timer Burden

 N/A 4 V·A

Certification

 N/A

Features

N/A The HQ9 offers accurate, efficient control for many industrial applications. These include motion control, electric heaters, ovens, program temperature controls, chemical feeding, and lubrication systems.

  • Electrically isolated pilot light
  • Cycle progress pointer
  • Compatible with CYCL-FLEX® series featuring unique plug-in mounting
