Technical Specs

Brands

 N/A
Dynapar™

NorthStar™

Model

 N/A 8500

Type

 N/A Incremental Encoder

Code

 N/A Incremental Magnetic

Resolution

 N/A 60 to 2,400 pulses/rev

Phasing Sense

 N/A A leads B for Counter-Clockwise rotation (CCW) viewing male C-face end

Quadrature Phasing

 N/A 90º ±45º

Symmetry

 N/A 50% ±15%

Number of Output Modules

 N/A Dual Single

Certification

 N/A

Key Features

N/A

  • New Sensor Provides up to 0.075" of Air Gap, Over 50% More Than Competitive Models
  • Expanded Resolution up to 2400PPR
  • Redesigned Circuitry for On-Board Diagnostics with LED and Alarm Output
  • Wide -40º to +100ºC Temperature Range
  • Optimized Pulse Wheel for Greater Shaft Holding Force and Ease of Assembly
