Technical Specs

Brands

 N/A
Dynapar™

Model

 N/A AI25 SSI/BiSS

Type

 N/A Absolute Encoder

Code

 N/A Absolute Optical

Resolution (Single-Turn)

 N/A 12 to 22 bits

Resolution (Multi-Turn)

 N/A 12 bits

Linearity

 N/A ± 1/2 LSB (± 1 LSB for resolution > 13 Bit

Absolute Accuracy (±)

 N/A 0.01º mechanical (36 arc-sec.)

Repeatability (±)

 N/A 0.002º mechanical (7.2 arc-sec.)

Certification

 N/A

Key Features

N/A

  • UL Certified for Class 1, Div 2 Group A,B,C,D Hazardous Applications
  • Up to 22 Bit Single-turn and 12 Bit Multi-turn
  • Onboard Alarm Diagnostics
  • SSI, SSI +Incr, BiSS-B, BiSS-C Interface
  • Approved PLTC Cable Included
  • Enclosure ratings of IP64 or IP66
