Technical Specs

Brands

 N/A
Dynapar™

Model

 N/A AI25 EtherNet/IP

Type

 N/A Absolute Encoder

Code

 N/A Absolute Optical

Resolution (Single-Turn)

 N/A 12 to 22 bits

Resolution (Multi-Turn)

 N/A 12 bits

Linearity

 N/A ± 1/2 LSB up to 14 Bit

Typical Absolute Accuracy (±)

 N/A 35 arc-sec or 0.01º

Typical Repeatability (±)

 N/A 10 arc-sec or 0.003º

Certification

 N/A

Key Features

N/A

  • Up to 34 Bit (22 Bit ST + 12 Bit MT)
  • Device Level Ring (DLR) and Address Conflict Detection (ACD)
  • High Speed 10,000 RPM Continuous
  • Hub Shaft and Shafted Models
  • Device Data: Position, Velocity, Acceleration, Alarms
  • Configuration Options: Resolution, Total Measuring Range, Preset, Direction, Scaling, Position-Velocity-Acceleration Limits
