Technical Specs

Brands

 N/A
Dynapar™

Model

 N/A AI25 CANopen

Type

 N/A Absolute Encoder

Code

 N/A Absolute Optical

Resolution (Single-Turn)

 N/A 10 to 16 bits

Resolution (Multi-Turn)

 N/A 12 bits

Linearity

 N/A ± 1/2 LSB

Absolute Accuracy (±)

 N/A 0.01º mechanical (36 arc-sec.)

Repeatability (±)

 N/A 0.002º mechanical (7.2 arc-sec.)

Certification

 N/A

Key Features

N/A

  • Up to 16 Bit of Single-turn and 12 Bits of True Multi-turn Absolute Positioning
  • Onboard Diagnostics
  • CAN Open Interface
  • Available with multiple shaft configurations
  • Enclosure ratings of IP64 or IP67
