Technical Specs
Brands |
N/A
 Autonics |
Model |
N/A TN |
Type |
N/A Temperature Controller |
Permissible Voltage Range |
N/A 90 to 110 % of rated voltage |
Display Type |
N/A 11 Segment, LCD type (operating value display part: 7 segment) |
Dielectric Strength |
N/A Between the charging part and the case: 3,000 VAC ~ 50/60 Hz for 1 minute |
Vibration |
N/A 0.75 mm amplitude at frequency of 5 to 55 Hz in each X, Y, Z direction for 2 hours |
Memory Retention |
N/A ≈ 10 years (Non-volatile Semiconductor Memory type) |
Ambient Temperature |
N/A -10 to 50 ºC, Storage: -20 to 60 ºC (No Freezing or Condensation) |
Ambient Relative Humidity |
N/A 35 to 85 % |
Power Consumption |
N/A ≤ 8 V·A |
Insulation Resistance |
N/A ≥ 100 MΩ (500 VDC, Megger) |
Noise Immunity |
N/A ±2 kV square shaped noise by noise simulator (pulse width: 1 ㎲) R-phase, S-phase |
Certification |
N/A
 |
Features
|
|
