Technical Specs
Brands |
N/A
 Autonics |
Model |
N/A TH4M |
Type |
N/A Temperature Controller |
Direct Current (DC) Power Supply Voltage |
N/A 100 to 240 V |
Permissible Voltage Range |
N/A 90 to 110 % of rated voltage |
Display Type |
N/A 11-Segment (temperature: white, humidity: blue), other display (yellow) Liquid Crystal Display (LCD) Type |
Dielectric Strength |
N/A Between the charging part and the case: 3,000 VAC 50/60 Hz for 1 minute |
Vibration |
N/A 0.75 mm amplitude at frequency 5 to 55Hz in each X, Y, Z direction for 2 hours |
Ambient Temperature |
N/A -10 to 50 ºC, Storage: -20 to 60 ºC (No Freezing or Condensation) |
Ambient Humidity |
N/A 35 to 85%RH, storage: 35 to 85%RH (No Freezing or Condensation) |
Power Supply Frequency |
N/A 50 Hz60 Hz |
Sampling Period |
N/A 1 sec |
Control Type |
N/A ON/OFF Control |
Certification |
N/A
 |
