Unit of Measure

Technical Specs

Brands

 N/A
Autonics

Model

 N/A TCN

Type

 N/A Temperature Controller

Permissible Voltage Range

 N/A 90 to 110 % of rated voltage

Display Type

 N/A 7 Segment (red, green), Light Emitting Diode (LED) Type

Vibration

 N/A 0.75 mm amplitude at frequency of 5 to 55 Hz in each X, Y, Z direction for 2 hours

Ambient Temperature

 N/A -10 to 50 ºC, Storage: -20 to 60 ºC (No Freezing or Condensation)

Ambient Humidity

 N/A 35 to 85%RH, storage: 35 to 85%RH (No Freezing or Condensation)

Sampling Period

 N/A 100 ms

Input Specification

 N/A Refer to 'Input Type and Using Range'.

Hysteresis

 N/A 1 to 100 ºC0.1 to 50.0 ºF

Integral Time (I)

 N/A 0 to 9,999 sec

Certification

 N/A

Features

N/A

  • Dual digital display (PV/SV)
  • 100 ms high-speed sampling rate and ±0.5% display accuracy
  • Switch between relay output and SSR drive output (patent)
  • SSR drive output (SSRP function) control options : ON/OFF control, cycle control, phase control
  • Compact design with large display panels for easier reading
  • Connector plug types offer easier wiring and maintenance (TCN4S-P) (Korea Patent Registration 10-1002582, U.S.A. Patent Registration 8645000, Japan Patent Registration 3184816, China Patent Registration ZL200980111733.X, Vietnam Patent Registration 1-0012131, India Patent Registration 291573, Indonesia Patent Registration IDP0032166)
