Technical Specs
Brands |
N/A
 Autonics |
Model |
N/A PMC-1HS / PMC-2HS |
Type |
N/A Motion Controller |
Power Supply |
N/A 24 VDC ± 10% |
Motor Control |
N/A Pulse input stepper motor or servo motor |
In-Position Setting |
N/A ABSOLUTE method INCREMENTAL method |
In-Position Range |
N/A -8,388,608 to +8,388,607 (available pulse scaling function) |
Drive Speed |
N/A 1 pps to 4 Mpps (1 to 8,000 pps x magnification 1 to 500) |
Pulse Output Method |
N/A 2 pulse output method (line driver output) |
Operation Mode |
N/A Continuous Mode Index Mode Jog Mode Program Mode |
Number of Drive Speed |
N/A 4 |
Program Save |
N/A Electrically Erasable Programmable Read-Only Memory (EEPROM) |
Steps |
N/A 64 |
Ambient Temperature |
N/A 0 to 45 ºC (No Freezing or Condensation) |
Ambient Humidity |
N/A 35 to 85% RH (No Freezing or Condensation) |
Certification |
N/A
 |
